(POS-1508-W/A) 15.8 Inch Andorid/Windows All-In-One Self-service POS System(POS-1508-W/A) 15.8 Inch Andorid/Windows All-In-One Self-service POS System(POS-1508-W/A) 15.8 Inch Andorid/Windows All-In-One Self-service POS System(POS-1508-W/A) 15.8 Inch Andorid/Windows All-In-One Self-service POS System(POS-1508-W/A) 15.8 Inch Andorid/Windows All-In-One Self-service POS System

(POS-1508-W/A) 15.8 Inch Andorid/Windows All-In-One Self-service POS System

  • Intel Celeron series and Android board for option;
  • Hard Driver Msata SSD 64GB ,SSD 128GB an 256 GB for option;
  • Multi-point projected capacitive touch panel;
  • Optional side MSR and VFD220 customer display;
  • Ture flat and water-proof/scratch-resistant surface display.

15.8 Inch Andorid/Windows All-In-One Self-service POS System

 (M/N:POS-1508-W/A)



OCOM Wide-screen POS terminal has stylish and ultra slim body desgin,It has Android and windows OS motherboard for option,it is easy to install 2nd display,MSR or VFD as moudules by customers.This model is very convenient for maintenance by removing the back cover and it has rich I/O interfaces to be connected to more external devices



Features:

Intel Celeron series and Android board for option

Hard Driver Msata SSD 64GB ,SSD 128GB an 256 GB for option

Multi-point projected capacitive touch panel

Optional side MSR and VFD220 customer display

Ture flat and water-proof/scratch-resistant surface display



Specification

Model

POS-1508-W

POS-1508-A

Name

15.8 inch Windows touch screen pos terminal

15.8 inch Android touch screen pos terminal

Housing

ABS plastic and metal combined

Color

Whole white color machine body usually

Display



Main screen size

15.8 inch touch screen monitor

Resoluiton

1920*1080

Brightness

350cd/m2

View angle

Horizon: 160; Vertical :150

Touch screen

Multi-point projected G+G capacitive touch

Sub-display

15.8 and 15.6 inch display W/o touch function, resolution1920*1080 resolution for option

Performance



Motherboard

Intel Celeron  Bay Trail J1900 2.0GHz usually  or intel core I3 / I5 4th generation CPU for option



ARM Cortex-A17 -RK 3288 quad core 1.8GHz CPU

System Memory

1*SO-DIMM DDRIII slot, support1333*/1600 4GB (default) 2GB/8GB for option

On board 2GB DDRIII,4GB for option

Storage device

Msata SSD 64GB or higer, up to 256GB

16GB eMMC, support 32GB TF card expanded

Audio

On board Real Tek ALC662 audio chip ALC5640

On board Real Tek audio chip ALC5640

LAN

10/100Mbs,Realtek RTL8111F Lan chip

built in Mini PCI-E slot,support embedded WIFI module

10M/100M RTL8201F,10M/100M/1000M RTL8211E for option

Operating System

Windows7/8/10,  Embedded,WEPOS,Linux





Android 8.1



Scanner

640*480 CMOS 1D/2D Barcode scanner

Speaker

4 Ohm 3W speaker

Printer

58/80 mm thermal printer with auto cutter

Connectivity



External I/O port(J1900 and RK3288)

power button*1

12V DC in jack*1

LAN:RJ-45*1

USB *5

N/A

TF card*1(SIM card*1 for option)

RJ11 for Cash drawer *1

Environment





Operating temperature

0 to 40 degrees centigrade

Storage temperature

-10 to 60 degrees centigrade

Working humidity

10%~80%    No condensation

Storage humidity

10%~90%    No condensation

Accessories



Power adapter

110-240V/50-60HZ AC power input ,DC12V/5A output adaptor

Power cable

Power cable plug compatible with USA /EU / UK etc and customized available

CD driver

Motherboard driver and touch driver inside

Other



Compliance

FCC Class A/CE Mark/LVD/CCC
