(OCBS-T201) Latest handfree 2d image barcode scanner(OCBS-T201) Latest handfree 2d image barcode scanner(OCBS-T201) Latest handfree 2d image barcode scanner(OCBS-T201) Latest handfree 2d image barcode scanner

(OCBS-T201) Latest handfree 2d image barcode scanner

  • High speed image acquisition and decoding
  • Can read the barcode on the screen
  • Omni-directional scanning,easy to scan
  • Desktop flatbed & Concise design
  • With steady stand & reliable scanner module

 Latest handfree 2d image barcode scanner

Can read the image acquisition and decoding

Omni-directional scanning,easy to scan
Desktop flatbed & Concise design
With steady stand & reliable scanner module
High speed image acquisition and decoding

Performance parameters

Light source

White LED

Buzzer

Seven tones or silent

Lamp

White

System interface

KBW, RS232,USB

Physical parameters

Volume(Lx W x H)

Product size 78 mm x 75 mm x 141mm (3.2˝ x 3.3˝ x 5.9˝),

Weight

Product size180 g (12 oz)

Electrical parameters

Input voltage

5.5 VDC ± 0.25 V

Work power

2.0 W (430 mA @ 5 V)

Standby power

0.5 W (100 mA @ 5 V)

Environmental parameter

Operating temperature

0° C - 40° C

Storage Temperature

-40°C -60°C

Humidity

0% to 95% relative humidity (no condensation)

Antiknock characteristic

Withstand 1.5 meters high drop from concrete floor.

Dust-proof

Seal to prevent air dust particle erosion.

Scanning parameters

Scanning mode

Omni directional (640X480)

Highest Reflectivity

Max 20% reflectivity can be read

Scanning Angle

70°, 75°


Relevant documents:

user manual
