200 Scans/s High Speed Wireless 1d Laser Handheld Barcode Scanner

  • 200MM/S Scan Speed
  • 10-60cm long depth of field
  • 70 m long Distance 2.4G Wireless transmission
  • Compatible with multiple language layouts
  • 1.5m free fall on concrete surface
  • 1500mAh lithium-ion battery

200 Scans/s High Speed Wireless 1d Laser Handheld Barcode Scanner

(OCBS-W013)

Specification:

Physical Parameters

Material

ABS+PVC+PC

Size

L*W*H: 162mm * 68mm * 93mm

Weight

169g±5g(without cord)

Power Supply

5V ±5% ,Built-in 3.7v 1500mAh lithium-ion battery

Operating current

50MA(operating mode); 30MA(standby mode)100MA(maximum peak)

Button Lifespan

>100000

Performance Parameters

Interface

USB cable;Wireless 2.4G transmission

System Supported

Linux,Android,Windows XP,7,8,10,MAC

Language Supported

English(Customizable language)

Light source

Visible laser diode, wavelength 650nm

Processor

32-bit MCU

Memory

64K(About 3500 14bit 1D barcodes)(the memory capacity can be customized)

Scanning speed

200 scans/sec

Resolution

4mil

Transmission Distance

70m

Bit Error Rate

1/5000000

Reading Mode

laser

Trigger Mode

Manual ;Continuous scanning

Charging time

6-7 hours

Working time

about 24 hours

Scanning Distance

10mm-600mm

Scanning Depth

Code39  5mil:3cm - 8cm
 Code39 10mil:4cm - 45cm

Environment Parameters

IP Grade

IP52

Storage Temp.

0 to 50ºC / 32 to 122ºF

Storage Humidity

20% to 85%(No Condensation)
