Android Desktop Omni-directional Bar code Scanner with Multiple InterfaceAndroid Desktop Omni-directional Bar code Scanner with Multiple InterfaceAndroid Desktop Omni-directional Bar code Scanner with Multiple InterfaceAndroid Desktop Omni-directional Bar code Scanner with Multiple InterfaceAndroid Desktop Omni-directional Bar code Scanner with Multiple InterfaceAndroid Desktop Omni-directional Bar code Scanner with Multiple Interface

Android Desktop Omni-directional Bar code Scanner with Multiple Interface

  • new high quality desktop omni barcode scanner
  • Number of Scan Lines:20;
  • Scan Pattern: 5 directions of scan field;
  • Multiple/Single line scanning capability, meet different requirement;
  • The base can be removed;
  • 650nm visible laser diodes (VLD) Source;
  • Scan Rate: 1500 scans per second (omni-directional);
  • Multiple interfaces: KBW, RS232 or USB optional.

Android Desktop Omni-directional Bar code Scanner with Multiple Interface

(OCBS-T009)

Features:

new high quality desktop omni barcode scanner
Number of Scan Lines:20;
Scan Pattern: 5 directions of scan field;
Multiple/Single line scanning capability, meet different requirement;
The base can be removed;
650nm visible laser diodes (VLD) Source;
Scan Rate: 1500 scans per second (omni-directional);
Multiple interfaces: KBW, RS232 or USB optional.


PERFORMANCE PARAMETERS

Light Source

Visible Laser Diode 650nm

Line

20 lines

Scan Rate

1800 scans per second (Omni-directional)

Scan Pattern

Omni-directional: 5 fields of 4 parallel lines

Print Contrast

32% minimum reflectance difference

Decode Capability

EAN-8, EAN-13, UPC-A, UPC-E, Code 39, Code 93, Code 128, EAN 128, ISBN,ISSN, Codabar, Code 25 non-interleaved, Code 25 interleaved , Matrix 2 of 5, MSI, PostBarcode, etc

ELECTRICAL PARAMETERS

Support Interface

PS/2, USB 2.0, RS232

Voltage Power

5VCD±12%  1.6W

Laser-level

Class2

Certificate

FCC, CE

LED Indicator

Red and Blue

PHYSICAL PARAMETERS

Weight (pc)

N.W: 474g/pc  G.W: 819g/pc

Size (pc)

Host: 115mm*110mm*152mm  Package: 245mm x165mmx132mm

Weight (Carton)

Package

9.6 kg/10pcs

Size (Carton)

680mm*350mm*280mm

ENVIRONMENTAL PATAMETER

Crash resistant

Can withstand 1.5M free fall

Operating Temperature

0 to 40 Degrees (32 Fahrenheit to 104 Fahrenheit)

Storage Temperature

-40 to 60 Degrees (-40 Fahrenheit to 140 Fahrenheit)

Humidity

5% to 95% Relative humidity, Non-condensing

Sealed Environment

IP54 (Sealed to resist airborne particulate contaminants)





FAQ:

1). MOQ policy
No MOQ limitation for the standard products, but the unit price is different, bigger quantity better price.
For customized production, you can discuss the MOQ with our sales representative directly.

2). Sample Availability & Policy
After customers confirmed the specification, we are very glad to provide samples for testing and qualification.
All samples should be paid before shippment, the samples price is a higher than mass order. When the mass order placed, we can return you the samples cost, or send you more piece products with the shippments.

You can buy the samples from us directly using t/t, western uion, or paypal. And you can also buy it on our online store at aliexpress:http://www.aliexpress.com/store/403448?tracelog=minisite_CI.

3). Warranty
OCOM is dedicated to providing most cost-effective products and services with reliable quality that will meet customers'satisfication;

We was qualified by global fortune 500 company, and we have the top 1 level trade assurance which 100% protect your money and lead time.

Our warranty of the products is about 12+1 months from the shipment normally, some designated models can have as long as 24 months warranty;

Any product within 30 days of delivery failure occurs shall be deemed invalid delivery (DOA). DOA products will give priority to the replacement, and shipped by courier.

For mass order, we would like to supply some spare parts with shipment for local quickly repair. And after that, you can returned failure parts for rework and analysis.

4). Payment Terms
For mass order, you can pay us by using T/T, LC, Western Union, Escrow or others. About samples order, T/T, Western Union, Escrow,Paypal are acceptable.Escrow Service is powered by Alipay.com. Currently,you can pay using Moneybookers, Visa, MasterCard and bank transfer. You can also pay with select debit cards including Maestro, Solo, Carte Bleue, PostePay, CartaSi, 4B and Euro6000.
