OCBP-M88 Shipping Label Printer 80mm Mini Portable 3 Inch Bluetooth Thermal Label Receipt PrinterOCBP-M88 Shipping Label Printer 80mm Mini Portable 3 Inch Bluetooth Thermal Label Receipt PrinterOCBP-M88 Shipping Label Printer 80mm Mini Portable 3 Inch Bluetooth Thermal Label Receipt PrinterOCBP-M88 Shipping Label Printer 80mm Mini Portable 3 Inch Bluetooth Thermal Label Receipt Printer

OCBP-M88 Shipping Label Printer 80mm Mini Portable 3 Inch Bluetooth Thermal Label Receipt Printer

  • Front paper output structure makes paper feed smoother and less jams
  • Fully body TPU wrap,strong anti-drop performance
  • Support label interval sensor
  • The width of the paper bin can be adjusted
  • 50 diameter paper roller can be installed
  • The USB Type-C interface can be both charge and communication
  • The LCD screen can directly observe the printer status
  • Support the physical button to set the printer
  • Free label editing software,convenient for end users to use directly

3 Inch Bluetooth Thermal Label/Receipt Printer

 (M/N:OCBP-M88)



Features:

  1. Front paper output structure makes paper feed smoother and less jams
  2. Fully body TPU wrap,strong anti-drop performance
  3. Support label interval sensor
  4. The width of the paper bin can be adjusted
  5. 50 diameter paper roller can be installed
  6. The USB Type-C interface can be both charge and communication
  7. The LCD screen can directly observe the printer status
  8. Support the physical button to set the printer
  9. Free label editing software,convenient for end users to use directly



Specification

General



Model

OCBP-M88

Color

Gray and white

Processor

32 bit CPU

Interface

USB type-C and Bluetooth

Printer head life

100Km

Battery

2600mAh, 7.4V 15Wh Non-removable battery

Charging time

4-5 hours

screen

1 inch TFT color screen

Sensors

Gap sensor,Cover opening sensor,Black mark sensor,Overheating sensor,paper end sensor

Working time

200meter printing, 7 days standby time

Power supply

5V DC/1A

Memory

8MB

software

Windows/Android/IOS/MAC

Safety standards

CE ,FCC,Rohs etc

Printing capability



Printing method

Direct Thermal

Resoluiton

8 dots/mm(203 DPI)

Print speed

80mm/s

Print width/ length

72mm Max/ 1778mm Max

Print command

ESC/POS, CPCL command

Barcode and character



Barcode

EAN-8, EAN-13, ITF, UPC-A, UPC-E, Codebar, Code93, Code39,

Code128,QR Code,PDF417,Data Matrix,Grid Matrix

Character set

Alphanumeric/ GBK/Unicode

Media



Media type

Continuous,Gap, Black mark

Media width

15-80mm

Media thickness

0.05-0.18mm

Media roll diameter

50mm Max

Physical



Dimension

102mm*113mm*57mm

Weight/Package box

Net:390g Gross:531.3g/192.5×129.4×63.8mm

16 in 1 carton

384×345×295mm/10kg

Environment



Working temperature&humidity

0 to 45 degrees centigrade,   10%~80%   No condensation

Storage temperature& humidity

-20 to 60 degrees centigrade ,  10%~90%  No condensation
