OCBS-D5000 Warehouse Android 7.0 1D 2D barcode scanner PDA device wifi 4G LTE NFC industrial handheld rugged PDAOCBS-D5000 Warehouse Android 7.0 1D 2D barcode scanner PDA device wifi 4G LTE NFC industrial handheld rugged PDAOCBS-D5000 Warehouse Android 7.0 1D 2D barcode scanner PDA device wifi 4G LTE NFC industrial handheld rugged PDAOCBS-D5000 Warehouse Android 7.0 1D 2D barcode scanner PDA device wifi 4G LTE NFC industrial handheld rugged PDAOCBS-D5000 Warehouse Android 7.0 1D 2D barcode scanner PDA device wifi 4G LTE NFC industrial handheld rugged PDA

OCBS-D5000 Warehouse Android 7.0 1D 2D barcode scanner PDA device wifi 4G LTE NFC industrial handheld rugged PDA

  • Android 7.0
  • 2GB RAM, 16GB ROM
  • Gorilla 5.0 in. 720*1280 Gorilla HD Screen
  • Rugged IP65/1.5 m Drop Tolerance
  • Rechargeable li-ion polymer, 3.7V, 4500 or 8000mAh Battery
  • Rear Camera 8 MP, auto-focus with LED flash
  • Support 4G/Wifi/GPS/Bluetooth
  • HHW Software Development Kit
  • 1D/2D Barcode Scanner(optional)
  • RFID LF/HF/UHF/NFC (optional)
  • TCS1SM Capacitive Fingerprint Sensor(optional)

OCBS-D5000 Warehouse Android 7.0 1D 2D barcode scanner PDA device wifi 4G LTE NFC industrial handheld rugged PDA

(Model no.: OCBS-D5000)


Feature:

- Android 7.0

- 2GB RAM, 16GB ROM

- Gorilla 5.0 in. 720*1280 Gorilla HD Screen

- Rugged IP65/1.5m Drop Tolerance

- Rechargeableli-ion polymer, 3.7V, 8000mAh Battery

- Rear Camera 8 MP,auto-focus with LED flash

- Support 4G/Wifi/GPS/Bluetooth

- HHW SoftwareDevelopment Kit

- 1D/2D BarcodeScanner(optional)

- RFIDLF/HF/UHF/NFC (optional)

- TCS1SMCapacitive Fingerprint Sensor(optional)



SPECIFICATIONS

PHYSICAL CHARACTERISTICS

Dimension

170mm(H)x85mm(W)x23mm(D)±2 mm

Weight

Net Weight :380g (including battery&wrist strap)

Display

Gorilla 5.0 in. TFT-LCD(720x1280)touch screen with backlight

Backlight

LED backlight

Keypads

3 TP keys, 6 function keys, 4 side buttons

Expansions

2 PSAM, 1 SIM, 1 TF

Battery

Rechargeable li-ion polymer, 3.7V, 8000mAh

PERFORMANCE CHARACTERSTICS

CPU

Quad A53 1.5GHz quad-core

Operating System

Android 7.0

Storage

2GB RAM, 16GB ROM, MicroSD(max 32GB expansion)

USER ENVIRONMENT

Operating Temp.

-20℃ to 50℃

Storage Temp.

-20℃ to 70℃

Humidity

5%RH to 95%RH(non-condensing)

Drop Specifications

5ft./1.5 m drop to concrete across the operating temperature range

Sealing

IP65, IEC compliance

ESD

±15kv air discharge, ±8kv direct discharge, ±8kv indirect discharge

DEVELOPMENT ENVIRONMENT

SDK

HHW Software Development Kit

Language

Java

Environment

Android Studio or Eclipse

DATA COMMUNICATION

WWAN

TDD-LTE Band 38, 39, 40, FDD-LTE Band 1,2,3, 4,7;

WCDMA(850/1900/2100MHz);

GSM/GPRS/Edge 850/900/1800/1900MHz);

WLAN

2.4G/5G Dual Frequency, IEEE 802.11 a/b/g/n/ac

WPAN

Bluetooth Class v2.1+EDR, Bluetooth v3.0+HS, Bluetooth v4.0

GPS

GPS(embedded A-GPS), accuracy of 5 m

DATA CAPTUER

BARCODE READER(OPTIONAL)

1D barcode

1D laser engine

Honeywell N431x

Symbologies

All major 1D barcodes

2D barcode

2D CMOS Imager

Honeywell N6603

Symbologies

PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode, Postal Codes, US PostNet, US Planet, UK Postal, Australian Postal, Japan Postal, Dutch Postal. etc.

COLOR CAMERA

Resolution

8.0 megapixel

Lens

Auto-focus with LED flash

RFID READER(OPTIONAL)

RFID LF

Frequency

125KHz/134.2KHz(FDX-B/HDX)

Protocol

ISO 11784&11785

R/W Range

2cm to 10 cm

RFID HF

Frequency

13.56MHz

Protocol

ISO 14443A&15693

R/W Range

2cm to 8cm

RFID UHF

Frequency

865~868MHz or 920~925MHz

Protocol

EPC C1 GEN2/ISO 18000-6C

Antenna Gain

Circular antenna(2dBi)

R/W Range

1 m to 1.5 m(tags and environment dependant)

Active 2.45GHz

Read range more than 200 m (customization)

433MHz

Read range more than 200 m (customization)

ZigBee READER(OPTIONAL)

Protocol

IEEE 802.15.4 (customization)

Reading Range

100 m to 200 m(customization)

FINGERPRINT READER(OPTIONAL)

Sensor

TCS1SM

Sensor type

Capacitive, area sensor

Resolution

508 DPI

Performance

FRR<0.008%, FAR<0.005%

Capacity

1000

PSAM SECURITY(OPTIONAL)

Protocol

ISO 7816

Baudrate

9600, 19200, 38400,43000, 56000, 57600, 115200

Slot

2 slots(maximum)

ACCESSORIES

Standard

1xPower Supply

1xLithium Polymer Battery

1xDC charging cable

1xUSB data cable

Optional

Cradle,Handle, UHF gain board







FAQ

1. MOQ policy

No MOQ limitation for the standard products, but the unit price is different, bigger quantity better price.

For customized production, you can discuss the MOQ with our sales representative directly.

2. Sample Availability & Policy
After customers confirmed the specification, we are very glad to provide samples for testing and qualification.

All samples should be paid before shippment, the samples price is a higher than mass order. When the mass order placed, we can return you the samples cost, or send you more piece products with the shippments.

You can buy the samples from us directly using t/t, western union, or paypal. And you can also buy it on our online store.

3. Warranty
OCOM is dedicated to providing most cost-effective products and services with reliable quality that will meet customers'satisfication;

We was qualified by global fortune 500 company, and we have the top 1 level trade assurance which 100% protect your money and lead time.

Our warranty of the products is about 12+1 months from the shipment normally, some designated models can have as long as 24 months warranty;

Any product within 30 days of delivery failure occurs shall be deemed invalid delivery (DOA). DOA products will give priority to the replacement, and shipped by courier.

For mass order, we would like to supply some spare parts with shipment for local quickly repair. And after that, you can returned failure parts for rework and analysis.

4. Payment Terms
For mass order, you can pay us by using T/T, LC, Western Union, Escrow or others. About samples order, T/T, Western Union, Escrow,Paypal are acceptable.Currently,you can pay using Moneybookers, Visa, MasterCard and bank transfer. You can also pay with select debit cards including Maestro, Solo, Carte Bleue, PostePay, CartaSi, 4B and Euro6000.

5. Shipment
We accept all kinds of shipping ways including: express, air, sea, truck, or pick up by customers personally.

6. Customer
Our main customers from Eruopean, Australia, and the fast growing South America, Africa, Russia...,

We have servered more than 2300 customers from 159 countries, including the global fortune 500 company like Unilever, O2.....50 of them are the biggest distributor in the local teritories.


Why You Choose OCOM?

·Leading One-Stop POS and Auto-ID Related Products Supplier Qualified by Global Fortune 500 Companies
·Tier 1 customers including Unilever, O2, Star...
·2300+ Customers Cover 159 Countries;
·11 Years OEM/ODM Experience.
·Top 1 Level Trade Assurance in POS industrial quarantee quality and shipment date
·Fast respondes and professional service
·ISO, FCC, CE , Soncap, POA, BIS, and other Certificates
·12+1 months wanrranty.
·Shortlisted in "China Best Employer Award"
·Belief: Integrity Based, Strive for Excellence, Win-win Cooperation

Company Information

OCOM Technologies Ltd. is the main supplier and manufacturer of POS and Auto-ID related products with TUV verified.

OCOM’s products portfolio covers Thermal Printer, Barcode Printer, Dot Matrix Printer, Barcode Scanner, POS Terminal, Magnetic Card Reader, Date terminal, and other POS Peripherals products(Cash Drawer,Customer Display,POS Monitor, POS keyboard,Money counter,Electronical Scale,Thermal Paper ), which are widely used for retailing, restaurant, bank, lottery, transportation, logistic, and other applications.  We have ISO, CE, FCC and other required certifications.

OCOM's mission is to be the compelling choice for our partners, and our three basic belief are "Integrity based, Strive for excellence, Win-win cooperation". We would like establish stable and reliable partnerships with customers all over the world. OEM/ODM is welcome.

Together we quest for the best.
