OCPP-M085 Wireless Receipt Printer Mini Portable 80mm Bluetooth Thermal Printer For Android IOSOCPP-M085 Wireless Receipt Printer Mini Portable 80mm Bluetooth Thermal Printer For Android IOSOCPP-M085 Wireless Receipt Printer Mini Portable 80mm Bluetooth Thermal Printer For Android IOSOCPP-M085 Wireless Receipt Printer Mini Portable 80mm Bluetooth Thermal Printer For Android IOSOCPP-M085 Wireless Receipt Printer Mini Portable 80mm Bluetooth Thermal Printer For Android IOS

OCPP-M085 Wireless Receipt Printer Mini Portable 80mm Bluetooth Thermal Printer For Android IOS

  • •Business style design, more fashion
  • •Support 1.D,2.D bar code printing
  • •While compatible with Windows, Linux, Android and IOS systems
  • •With 2500mAh rechargeable lithium polymer battery,super battery lasting time, with smart power saving and power consumption control functions , to ensure longer print time
  • •Support USB+COM +Bluetooth or USB+COM+Bluetooth+WIFI,
  • •Special power remaining indicator light, to control the printer power at any time
  • •Support sound and light reminder when lack of paper or printing abnormal
  • •Anti fall of 1.5M cement floor
Wireless Receipt Printer Mini Portable 80mm Bluetooth Thermal Printer For Android IOS
(Model No.: OCPP-M085)

Products Features:
1. Business style design, more fashion
2. Support 1.D,2.D bar code printing
3. While compatible with Windows, Linux, Android and IOS systems
4. With 2500mAh rechargeable lithium polymer battery,super battery lasting time, with smart power saving and power consumption control functions , to ensure longer print time
5. Support USB+COM +Bluetooth or USB+COM+Bluetooth+WIFI,
6. Special power remaining indicator light, to control the printer power at any time
7. Support sound and light reminder when lack of paper or printing abnormal
8. Anti fall of 1.5M cement floor

Application:

Warehousing, transportation, logistics, supermarket, tobacco, hydropower reading, mobile government affairs,mobile police, postal and other industries

Parameters
:
Item Parameter








Print parameter
Printing Method Thermal Line
Effective Printing Width  72mm
Resolution 576 dots/line(8dots/mm,203dpi)
Priting Speed 90mm/S
Interface USB (standard USB2.0 communication protocol, support Windows, Linux, Android, IOS)
Bluetooth (Bluetooth2.0, Bluetooth3.0+4.0,support Android, IOS)
WIFI (2.4GHZ, ATA, AP, ATA+AP mode)
Line spacing 3.75mm(Can adjust line spacing by command)
Line No. Font A:48 character /Line
Font B:64 character/Line
Simple,traditional Chinese-24 lines
Character The standard GB18030 simplified / traditional Chinese characters library
Character Size ANK character,Font A:1.5×3.0mm(12×24 dots)
Font B:1.1×2.1mm(9×17 dots) Simplified/Traditional:3.0×3.0mm(24×24dots)




Bar code character
Extended character set PC437/Katakana/PC850/PC860/PC863/PC865/WestEurope/Greek/Hebrew/
EastEurope/Iran/WPC1252/PC866/PC852/PC858/IranII/Latvian/Arabic/PT151,
1251/PC737/WPC/1257/ThaiVietnam/PC864/PC1001/(Latvian)/(PC1001)/(PT151,1251)/(WPC1257)/(PC864)/(Vietnam)/(Thai)
Bar code 1D.Bar code:UPC-A/UPC-E/JAN13(EAN13)/JAN8(EAN8)CODE39/ITF/
CODABAR/CODE93/CODE128
2D.Bar code:QRCODE
Graphics printing Graphics printing Supports bitmap download and print



Power saving Mode
Smart power saving Support
Variable speed printing Support
Consumption Support
Dormancy Support
Dection Sensor Lack of paper detection
Indicator Power Display Support
Charge Indicator Support
Lack of paper Support
Beep Lack of paper,printing abnormal alarm
Paper Type Thermal
Width 79.5±0.5mm
thickness ≤0.12mm
Diameter ≤40mm
Feed Easy(Clameshell feed)
Print commands Commands ESC/POS
Power Type Rechargeable Lithium polymer battery
Capacity 2500mAh/7.4V, can be charged more than 800 times
sustainable printing 150 meters or 4 hours under normal use
Charger 9.0V/2A
Buffer Input 4KB
NV Flash 40KB
Physical features Weight 285G
Dimension 114*103*50(MM)
Environment Operating Temp:5 ~ 45ºC, Humidity:10 ~ 80%
Storage Temp:-10 ~ 50ºC ,Humidity:10 ~ 90%(No Dew)
Reliability Print head life 50KM(Printing Density≤12.5)
Software Driver Android,IOS,Linux,,WinXP,Win7,Win8,Win8.1,Win10

Portable Printer Application Area:

Compared to the traditional thermal receipt printer, mini printer has smaller body, more reliable capability, more steady printing and portable advantages. The Mini printer can work on a lot of locations, such as the TAXI bill printing, administrative fees receipt printing, post receipt printing, restaurant ordering information printing, online payment information printing, etc. With the rapid popularity of smart-mobile, tablet and so on, Mini printer will be more widely used in the near future.

 Power adaptor for option:
Europe, British, America, Australia, Asia etc.

Production capacity and lead time:
We have strong production capacity; we can produce thousand of printers and barcode scanners per day. Normally, our lead time between 1-5 days.

Shipping method:
Air, Sea, Express (DHL, FedEx, UPS, EMS, TNT and so on)

Warranty:
12+1 months of shipment normally. Some designated models can have as long as 24 months warranty. Spare parts can be provided for mass order.

Payment term:
T/T in advance, Western Union, PayPal, Escrow, L/C, Cash, etc
