(POS-Q1/Q2) Android Portable POS Terminal with 58mm thermal Printer(POS-Q1/Q2) Android Portable POS Terminal with 58mm thermal Printer(POS-Q1/Q2) Android Portable POS Terminal with 58mm thermal Printer(POS-Q1/Q2) Android Portable POS Terminal with 58mm thermal Printer(POS-Q1/Q2) Android Portable POS Terminal with 58mm thermal Printer

(POS-Q1/Q2) Android Portable POS Terminal with 58mm thermal Printer

  • Android 8.1 operating system;
  • 2G/3G/4G communication for Optional;
  • Q1:4G, Quad core MTK6737,1.25GHZ Processor;
  • Q2:3G, Quad core MTK6580,1.3GHZ Processor;
  • 2G RAM+16G Storage for Q1;
  • 1G RAM+8G Storage for Q2;
  • Built-in high speed 58mm thermal printer module;
  • Built-in 5 megapixels camera;
  • Built-in large volume speaker;
  • CCD Barcode scanner for optional;
  • NFC (HF) function for optional;
  • Support 12V DC interface charging;
  • 5000mAh large capacity battery.

Android Portable POS Terminal with 58mm thermal Printer

(M/N: POS-Q1/Q2)



Features:

Android 8.1 operating system;

2G/3G/4G communication for Optional;

Q1: 4G, Quad core MTK6737,1.25GHZ Processor;

Q2: 3G, Quad core MTK6580,1.3GHZ Processor;

2G RAM+16G Storage for Q1;

1G RAM+8G Storage for Q2;

Built-in high speed 58mm thermal printer module;

Built-in 5 megapixels camera;

Built-in large volume speaker;

CCD Barcode scanner for optional;

NFC (HF) function for optional;

Support 12V DC interface charging;

5000mAh large capacity battery.



Spec:

O/S

Android 8.1

CPU

Quad core MTK6737,1.25GHZ (Q1,4G) /

Quad core MTK6580,1.3GHZ (Q2,3G)

RAM

1GB for Q2 /2GB for Q1

Flash

8GB Flash for Q2 / 16GB Flash for Q1

Display

5.5" HD Screen, Highest Resolution 1280 x 720

Touch

Capacitive Multi point Touch

Camera

5,000,000 Fixed Focus

Scanner

1D CCD Scanner (Option)

RFID

13.56MHZ 14443A NFC (HF)

Network

GSM900/1800 WCDMA2100 TD-SCDMA:B34 B39/ FDD-LTE:B1 B3 / TDD-LTE:B38 B39 B40 B41

Bluetooth

Bluetooth 4.0

WIFI

WIFI 802.11 b.g.n

Speaker

1W Single Channel

Microphone

MIC Input

Button

Power button, Scan Button

I/O

Charging Socket, USB, SIM Slot

Battery

7.4V / 5000mAh

Printer

58mm Thermal Receipt Printer, Printing Speed 90mm/s,

Work Life 50 Km

Paper Roll

Max Diameter 42mm

Power Adapter

Input:100-240V/1.5A 50/60Hz

Output:12V 1A

Dimension

209.2mm (L) x 87.4mm (W) x 51.7mm (H)













Relevant documents:

    POS-Q1/Q2 Spec

     POS-Q1/Q2 SDK

         POS-Q2 Portuguese in Portuguese User's Manual







GL-V1, GL-V2, JP-Q1, JP-Q2, golink, go-link, sunmi, sunmi P1, SUNMI V1s, SUNMI V2, SUNMI V2 PRO
