RS232 Auto Cutter QR Code POS Receipt Dot-matrix PrinterRS232 Auto Cutter QR Code POS Receipt Dot-matrix PrinterRS232 Auto Cutter QR Code POS Receipt Dot-matrix PrinterRS232 Auto Cutter QR Code POS Receipt Dot-matrix PrinterRS232 Auto Cutter QR Code POS Receipt Dot-matrix Printer

RS232 Auto Cutter QR Code POS Receipt Dot-matrix Printer

  • 76MM impact dot matrix receipt printer with automatic cutter;
  • Compatible with EPSON;
  • With Black mark detection function;
  • Multiple interfaces available: Serial /parallel/USB/LAN;
  • Support cash drawer kick out;
  • Easy operation and elegant appearance.

RS232 Auto Cutter QR Code POS Receipt Dot-matrix Printer

(M/N:OCPP-763)

Feature:

76MM impact dot matrix receipt printer with automatic cutter;
Compatible with EPSON;
With Black mark detection function;
Multiple interfaces available: Serial /parallel/USB/LAN;
Support cash drawer kick out;
Easy operation and elegant appearance.


Specifications:

Printing method

9 pins serial dot matrix

Print font

FONT A: 33 or 35; FONT B: 40 or 42

Column capacity

400dots

Character size

ANK, Font A:9*9dots, Font B:7*9dots Simplified Chinese,
traditional Chinese:16*16dots

Character set

Buyer option

Character per line

400dots

Printing speed

4.5lines/sec

Receive buffer

Selectable as 45 bytes or
4k bytes using Dip switches

Paper width

75.5±0.5mm

Copy capability

One original and two copies

Ribbon

ERC-39

MCBF(life)

10,000,000 lines

Driver

Win9X/Win ME/Win2000/Win2003/WinNT/Win XP/Win Vista/Win 7/Linux

CPU

32 bit

Storage environment

Temperature (-10~60°c) humidity (10~90%)

Working environment

Temperature (0~50°c) humidity (10~90%)

Dimension

230X146X145mm

Gross weight

3.75KG

Auto cutter

Yes

Paper end sensor

Yes

Paper thickness

0.06-0.08mm

Roll paper

75.5±0.5mm*  φ65mm

Interface

Serial/parallel/USB/ LAN

Command

Compatible with EPSON

Cash drawer control

DC 12-24V/1A

Power supply

DC24V/2.5A

Notes: It uses a highly reliable Japanese print head(SEIKO F347) with a life span rated at more than 10,000,000 lines
