desktop 80mm Receipt Thermal Printer with usb port

  • Desktop or wall-mounted type for option.
  • Supports multi 1D barcodes and 2D codes printing.
  • USB+RS232+LAN,3 interface
  • 300mm /S high printing Speed
  • 100M Ethernet port ultra high speed data transmission.
  • Supports 256KB NV Logo storage and 2M big buffer memory.
  • Supports black mark detection and order reminding function,
  • Compatible with OPOS driver.

desktop 80mm Receipt Thermal Printer with usb port

(Model No.: OCPP-80H)


 Features:

 Desktop or wall-mounted type for option.

 Supports multi 1D barcodes and 2D codes printing.

 USB+RS232+LAN,3 interface

 300mm /S high printing Speed

 100M Ethernet port ultra high speed data transmission.

 Supports 256KB NV Logo storage and 2M big buffer memory.

 Supports black mark detection and order reminding function,

 Compatible with OPOS driver.


Technical parameters:

Printing method:

Direct thermal

Printing speed:

300mm/s

Roll width:

79.5±0.5mm

Print diameter:

Φ80mm

Paper thickness:

0.06-0.08mm

Column capacity:

576dots/line512 Dots/line

Line’s pacing :

3.75mm(Adjustable by commands)

Print command:

Compatible with the ESC/POS command

Interface type:

Serial+USB+LAN

Cutters life:

1million cuts

Print head life:

100 km

Input buffer :

2048Kbytes

NV Flash:

256Kbytes

Power adaptor:

AC110V/240V、50~60Hz

Power supply:

DC 24V/2.5A

Cash drawer supply:

DC 24V/1A

Work environment:

Temperature(0~45) humidity(10~80%)(Non- condense)

Work environment:

Temperature(0-45) degree centigrade, humidity(10-80%) Non- condense

Storage environment:

Temperature(-10~60℃); Humidity(10~90%)

Character size:

ANK,FontA:1.5*3.0mm/ FontB:1.1*2.1mm

Barcode:

UPC-A/UPC-E/JA(EAN13)/JAN8(EAN8/CODE39/ITF

/CODE93/CODE128/QRCode/PDF417 (options)

Characters:

PC347(Standard Europe)、Katakana、PC850(Multilingual)、PC860(Portuguese)、PC863(Canadian-French)、PC865(Nordic)、West Europe、Greek、Hebrew、East Europe、Iran、WPC1252、PC866(Cyrillic#2)、PC852(Latin2)、

PC858、IranII、Latvian、Arabic、PT151(1251)


FAQ

1. MOQ policy
No MOQ limitation for the standard products, but the unit price is different, bigger quantity better price.

For customized production, you can discuss the MOQ with our sales representative directly.

2. Sample Availability & Policy
After customers confirmed the specification, we are very glad to provide samples for testing and qualification.

All samples should be paid before shippment, the samples price is a higher than mass order. When the mass order placed, we can return you the samples cost, or send you more piece products with the shippments.

You can buy the samples from us directly using t/t, western uion, or paypal. And you can also buy it on our online store at aliexpress:http://www.aliexpress.com/store/403448?tracelog=minisite_CI.

3. Warranty
OCOM is dedicated to providing most cost-effective products and services with reliable quality that will meet customers'satisfication;

We was qualified by global fortune 500 company, and we have the top 1 level trade assurance which 100% protect your money and lead time.

Our warranty of the products is about 12+1 months from the shipment normally, some designated models can have as long as 24 months warranty;

Any product within 30 days of delivery failure occurs shall be deemed invalid delivery (DOA). DOA products will give priority to the replacement, and shipped by courier.

For mass order, we would like to supply some spare parts with shipment for local quickly repair. And after that, you can returned failure parts for rework and analysis.

4. Payment Terms
For mass order, you can pay us by using T/T, LC, Western Union, Escrow or others. About samples order, T/T, Western Union, Escrow,Paypal are acceptable.Escrow Service is powered by Alipay.com. Currently,you can pay using Moneybookers, Visa, MasterCard and bank transfer. You can also pay with select debit cards including Maestro, Solo, Carte Bleue, PostePay, CartaSi, 4B and Euro6000.

5. Shipment
We accept all kinds of shipping ways including: express, air, sea, truck, or pick up by customers personally.

6. Customer

Our main customers from Eruopean, Australia, and the fast growing South America, Africa, Russia...,

We have servered more than 1300 customers from 133 countries, including the global fortune 500 company like Unilever, O2.....50 of them are the biggest distributor in the local teritories.
