    (ECD460) 460mm Width Big Electronic Metal Cash Drawer(ECD460) 460mm Width Big Electronic Metal Cash Drawer

    (ECD460) 460mm Width Big Electronic Metal Cash Drawer

    • 5 Bill holders and 8 Coins holders
    • All Steel Construction and Textured hybrid powder coat
    • 12V or 24V for option
    • Optional Micro-switch Sensor
    • 3-position locks
    • Manual open available



    460mm Width Big Electronic Metal Cash Drawer

     (Model No.: ECD460)

    Features:



    l  5 Bill holders and 8 Coinsholders

    l  All SteelConstruction and Textured hybrid powder coat

    l  12V or 24V for option

    l  Optional Micro-switchSensor

    l  3-position locks

    l  Manual open available



    Specifications:



    Material

    Flip top: 0.8mm SPCC powder spray the surface of cold rolled plate

    Bottom: 1.0mm SECC fingerprint-resistant plate

    Bill tray

    Five position width:84/84/79/73/71mm

    Length:180mm; Depth: 53mm

    Coin tray

    front four position: width: 56; depth: 43 length (adjustable): 94/98/98/94;

    Rear four rows:  width: 63; depth: 45 length (fixed): 94/98/98/94;

    lock

    3 locks

    Power

    12V / 24V for option

    Lifetime

    Tested to minimum one million cycles

    Interface

    RJ12, Micro Switch (optional)

    Color

    Black

    weight

    8.5KG (net), 9.5KG (gross)

    Drawer Dimensions

    460(W)X465(D)X100(H)

    Package Dimensions

    510(W)X540(D)X155(H)
