    (OCBS-2015) High Performance Decoding Android handheld 1D 2D QR Code Barcode Scanner(OCBS-2015) High Performance Decoding Android handheld 1D 2D QR Code Barcode Scanner(OCBS-2015) High Performance Decoding Android handheld 1D 2D QR Code Barcode Scanner(OCBS-2015) High Performance Decoding Android handheld 1D 2D QR Code Barcode Scanner(OCBS-2015) High Performance Decoding Android handheld 1D 2D QR Code Barcode Scanner

    (OCBS-2015) High Performance Decoding Android handheld 1D 2D QR Code Barcode Scanner

    • High Performance Decoding;
    • With IR Sensor to Detect Moving Barcode;
    • Humanized Lighting & Focus Design;
    • Strong Data Editing Function;
    • Reliable and Durable Structural Design;
    • Low Power Design Compatible with All Types of Devices.

    High Performance Decoding Android handheld 1D 2D QR Code Barcode Scanner

    (Model No.: OCBS-2015)



    Feature:

    ·High Performance Decoding

    Can read up to 3mil barcodes, DPM barcodes on spare parts, OCR barcodes and can take picture.

    ·Strong Data Editing Function

    Some functions can be set on scanners before sending data to host machine. It help to input data as a requested way to achieve the goal of editing data flexible.

    ·With IR Sensor to Detect Moving Barcode

    IR function can detect upto 40cm moving barcode, and decoding within 100ms.

    ·Reliable and Durable Structural Design

    Can withstand repeated drops from a height of 1.8 meters, IP42 protection level.

    ·Humanized Lighting & Focus Design

    The soft illumination without flash frequency and a clear/accurate cross laser focusing system not only produce visual fatigue in continuous high-strength operating conditions, but also greatly improve the efficiency of operation.

    ·Low Power Design Compatible with All Types of Devices

    Low power design can help to solve the connection problems which caused by insufficient USB drive capacity on the host computer or excessive voltage requirements for the access device etc. It help to maximize the compatibility of the device.



    Application:

    Retrospective management of production in electronic industry, retrospective management of light industry production, warehouse management of online shop, logistics, and normal barcode scanner application etc.



    Specification:

    Scan

    Sensor

    CMOS

    Accuracy*

    ≥3mil

    Resolution

    1280*960

    Movement Tolerance*

    2 m/s

    Light

    White LED /Red LED

    Field of view angle

    Horizontal40.5°, Vertical30.4°

    Focus

    Laser 650nm

    Symbolic contrast*

    ≥25%







    Barcodes

    2D

    PDF417, QR Code, Data Matrix, Chinese Sensible Code(汉信码),etc.

    1D

    EAN-13, EAN-8, UPC-A, UPC-E, ISSN, ISBN, Codabar, Code 128, Code93, ITF-6,

    ITF-14,Interleaved2of 5,Industrial 2of 5,Standard 2of5,Matrix2of 5, GS1 Databar, Code

    39, Code 11, MSI-Plessey, Plessey,etc.





    Reading Depth*

    Barcode Type

    2015-1

    2015-2

    EAN-13(13mil)

    25mm~155mm

    40mm~410mm

    Code 39(5mil)

    50mm~100mm

    110mm~250mm

    PDF 417(6.7mil)

    40mm~105mm

    115mm~190mm

    Data Matrix(10mil)

    40mm~110mm

    100mm~250mm

    QR Code(15mil)

    35mm~155mm

    70mm~280mm

    Barcode Sensitivity*

    Pitch

    ±50°



    Tilt

    360°



    Skew

    ±50°



    Electrical

    Interface

    RS-232,USB,PS/2

    Prompt method

    Buzzer, LED indication, vibrator

    Dimension

    166(W)*107(D)*71(H)mm

    Voltage

    5 VDC±5%

    Weight

    208g

    Rated power

    consumption

    1251 mW(Typical values)

    Current@5 VDC

    Operating current 266 mA (Typical Values)

    Standby current

    109 mA

    Environmental

    Working Temperature

    -20℃~50℃

    Electrostatic

    ±16 kV (Air discharge), ±8 kV (direct discharge)

    Storage Temperature

    -40℃~+70℃

    Anti Drop

    1.8m

    Humidity

    5%~95%(Non-condensing)

    IP Grade

    IP42

    Certificates

    FCC Part15 Class B, CE EMC Class B

    Accessories

    cable

    USB

    USB cable, for connection and transmission

    RS-232

    RS-232 cable(optional), for connection and transmission

    PS/2

    PS/2 cable(optional), for connection and transmission

    adapter

    5V adapter(optional), forRS232 power supply.

    Out put: DC 5V, 1.5A. Input: AC100~240V, 50~60Hz

    Others

    Intelligent Induction Stand

    Optional

    Data Editing

    Supported
