(OCBP-006) 2 Inch Direct Thermal Barcode Label Printer support thermal roll paper and adhesive paper(OCBP-006) 2 Inch Direct Thermal Barcode Label Printer support thermal roll paper and adhesive paper(OCBP-006) 2 Inch Direct Thermal Barcode Label Printer support thermal roll paper and adhesive paper(OCBP-006) 2 Inch Direct Thermal Barcode Label Printer support thermal roll paper and adhesive paper

(OCBP-006) 2 Inch Direct Thermal Barcode Label Printer support thermal roll paper and adhesive paper

  • 1.Support thermal roll paper / adhesive paper
  • 2.The print head with adjustable pressure
  • 3.Automatic paper checking function
  • 4.Temperature adaptive control
  • 5.Modular design, to meet different application requirements

2 Inches Direct Thermal Label Printer

      (M/N:OCBP-006)



1.Support thermal roll paper / adhesive paper
2.The print head with adjustable pressure
3.Automatic paper checking function
4.Temperature adaptive control
5.Modular design, to meet different application requirements

label printing machine,barcode label thermal printer,direct thermal label printer



Printing method

Direct thermal

Resolution

203DPI

Print width

20-60mm

Printing speed

MAX:127mm/sMIN:50.8mm/s

Memory

DRAM: 4M FLASH: 4M

Print head temperature

Thermistor

Paper exists detection

The micro switch

Interface

USB

Paper presence detection

Paper presence detection

Barcode

CODE128EAN128ITFCODE39CODE93EAN13EAN13+2EAN13+5EAN8EAN8+2EAN8+5CODABARPOSTNETUPC-AUPCA+2UPCA+5UPC-EUPCE+2UPC-E+5CPOSTMSIMSICPLESSEYITF14EAN14 Qrcode、 DM Code、 PDF417

Internal font

FONT 0 to FONT 8

Enlargement & rotation

90°270° 360° 1 to 10 times enlargement in both direction; 0°90°270° 360° rotation


Monochromatic PCX, BMP image files can be load to FLASH, DRAM

Paper type

Paper roll, sticker, adhesive sticker, etc

Paper width

20mm60mm

Roll external

MAX 80mm

Roll inner diameter

MIN 25mm

Paper off  type

Tear off

Power supply input

DC12V, 3A

Weight

1.04KG

Dimensions

190(D) x 135(W) x 137(H)mm

Work environment

545, 2080%RH(no condensation)

Storage

4055℃,≤93%RH40℃)

environment



Relevant documents:

OCOM Label Printer Software and Driver
